Wirtgen · Cold Milling Machines
Wirtgen W 100 HR
Also available as W 50 HR, W 130 HR, W 55 HR
- 1,000 mm
- Milling Width
- 13,600 kg
- Operating Weight
- 200 mm
- Max Milling Depth
- 155 kW
- Engine Power
The Wirtgen W 155 CF is a compact-class cold milling machine featuring an integrated primary crusher and conveyor system, a tracked undercarriage, and a milling drum designed for direct material loading and efficient recycling on medium-scale road rehabilitation projects.
Wirtgen W 155 CF
Compact front loading milling machine at 1,500 mm, combining small machine manoeuvrability with large machine output.
- 1,500 mm
- Milling Width
- 20,650 kg
- Operating Weight
- 330 mm
- Max Milling Depth
- 276 kW
- Engine Power
Talk to a specialist
Add W 155 CF and any other machines to one enquiry. We do not publish prices, our team will call you to discuss specification.
Wirtgen W CF Series
2 builds, differing by milling width
W 155 CF1,500 mmW 185 CF1,900 mm
Milling Width: 1,500 mm, 1,900 mm. Operating Weight: 20,650 kg, 21,000 kg
Front discharge keeps the working train short
1,500 mm width with 330 mm depth
Large machine output in a compact footprint
Suits confined and urban sites
Compact front loading milling machine at 1,500 mm, combining small machine manoeuvrability with large machine output.
Front loading discharges milled material ahead of the machine, so the truck runs in front rather than behind and the whole train fits in a shorter working space. The CF class exists for sites that need large machine output but cannot give a large machine room to work.
Key Features
- Front discharge keeps the working train short
- 1,500 mm width with 330 mm depth
- Large machine output in a compact footprint
- Suits confined and urban sites
At a Glance
- Milling Width
- 1,500 mm
- Operating Weight
- 20,650 kg
- Max Milling Depth
- 330 mm
- Engine Power
- 276 kW
About Wirtgen: Cold milling machines for surface layer removal, full depth rehabilitation and fine milling, supplied through Wirtgen India.
View the full Wirtgen rangeFull technical data for the W 155 CF. These figures also power the catalogue filters, so what you filter on is what is shown here.
Engine & Power
| Engine Power (kW) | 276 kW |
|---|---|
| Emission Standard | CEV Stage V |
Weight & Dimensions
| Operating Weight (kg) | 20,650 kg |
|---|
Milling Performance
| Milling Width (mm) | 1,500 mm |
|---|---|
| Max Milling Depth (mm) | 330 mm |
Specifications are indicative and subject to confirmation against the current datasheet. Contact our team for available options and configurations.
How well this machine suits each type of work, rated by our team rather than derived from a generic rule.
Road Rehabilitation
Best matchMilling out failed layers and rebuilding existing roads, including cold recycling in place.
94% fit
Urban Roads & Streets
Strong matchCity streets, lanes and confined urban sites where compact machines and manoeuvrability matter more than output.
82% fit
Highway Construction
Strong matchNew national highway alignments and multi-lane carriageways requiring high output paving and compaction.
80% fit
Documentation for the W 155 CF. The spec sheet is generated from the same data as this page, so it can never contradict it.
W 155 CF Specification Sheet
Branded, print ready, always current. Opens in the browser and saves as PDF.
Ask us for any document you need and we will send it directly.
Keep it running
Recommended Spare Parts
The parts most often needed for the W 155 CF, ordered by how quickly their wear stops the machine. Add any of them to the same enquiry as the machine.
WIR-017Carry a spareDrive belt set, engine to pumpEngine to hydraulic pump transmissionWIR-020Carry a spareChassis grease, lithium EP2Drum lift, tracks, chassis linkageWIR-012Carry a spareEngine oil, 15W-40 dieselDiesel engine, per service intervalWIR-015Carry a spareHydraulic oil, HVLP 46Propulsion, levelling and drum lift hydraulicsWIR-010Carry a spareMilling drum gearbox oilDrum drive gearboxWIR-016Carry a spareAir filter elementEngine intake
