A promotional shot of the SUPER 800-5 P mini paver on a job site, showcasing its compact frame and screed unit ready for small-scale asphalt paving work
Vögele SUPER 800-5 P
Wheeled mini class paver for car parks, minor roads and sports grounds.
- 1.4 to 3.5 m
- Paving Width
- 300 t/h
- Max Laydown Rate
- 55.4 kW
- Engine Power
Talk to a specialist
Add SUPER 800-5 P and any other machines to one enquiry. We do not publish prices, our team will call you to discuss specification.
Vögele Mini Class
3 builds, differing by width and running gear
Paving Width: 0.9 to 1.8 m, 0.92 to 1.8 m, 1.4 to 3.5 m. Max Laydown Rate: 20 t/h, 20 t/h, 300 t/h
Wheeled, relocates under its own power
Up to 3.5 m paving width
Car parks, minor roads, sports grounds
300 t/h laydown rate
Wheeled mini class paver for car parks, minor roads and sports grounds.
A wheeled machine relocates under its own power, which matters when the work is scattered across a site rather than continuous. At up to 3.5 m paving width it covers car parks, estate roads and sports surfaces that are too large for a MINI and too small for a universal class paver.
Key Features
- Wheeled, relocates under its own power
- Up to 3.5 m paving width
- Car parks, minor roads, sports grounds
- 300 t/h laydown rate
At a Glance
- Paving Width
- 1.4 to 3.5 m
- Max Laydown Rate
- 300 t/h
- Engine Power
- 55.4 kW
About Vögele: Asphalt pavers from mini class through highway class, including the SUPER 1400i produced in India since 2016.
View the full Vögele rangeFull technical data for the SUPER 800-5 P. These figures also power the catalogue filters, so what you filter on is what is shown here.
Engine & Power
| Engine Power (kW) | 55.4 kW |
|---|
Paving Performance
| Paving Width (m) | 1.4 to 3.5 m |
|---|---|
| Max Laydown Rate (t/h) | 300 t/h |
Specifications are indicative and subject to confirmation against the current datasheet. Contact our team for available options and configurations.
How well this machine suits each type of work, rated by our team rather than derived from a generic rule.
Urban Roads & Streets
Best matchCity streets, lanes and confined urban sites where compact machines and manoeuvrability matter more than output.
92% fit
Road Rehabilitation
SuitableMilling out failed layers and rebuilding existing roads, including cold recycling in place.
70% fit
The service schedule for the Vögele Mini Class, by hour meter reading. Every build in the family shares it. Our service team carries these out, and the parts each one needs are held in Kathmandu.
- 150 hGear oil and filter change
- 2100 hEngine oil and filter change
- 3500 hEngine oil, gear oil and filter change
- 41,000 hEngine oil, gear oil and hydraulic oil filter change
Readings are the manufacturer's intervals. Dust, gradient and duty cycle all shorten them in practice, so treat these as the latest a service should happen rather than the earliest.
Book a serviceDocumentation for the SUPER 800-5 P. The spec sheet is generated from the same data as this page, so it can never contradict it.
SUPER 800-5 P Specification Sheet
Branded, print ready, always current. Opens in the browser and saves as PDF.
Ask us for any document you need and we will send it directly.
Keep it running
Recommended Spare Parts
The parts most often needed for the SUPER 800-5 P, ordered by how quickly their wear stops the machine. Add any of them to the same enquiry as the machine.
VOG-016Carry a spareDrive belt set, engine to pumpEngine to hydraulic pump transmissionVOG-012Carry a spareAuger gearbox oil, gear oil 90Auger drive gearboxVOG-018Carry a spareChassis grease, lithium EP2All grease nipples: chassis, screed linkage, tow pointsVOG-002Carry a spareEngine oil, 15W-40 dieselDeutz or Cummins engine, per service intervalVOG-005Carry a spareHydraulic oil, HVLP 46Propulsion, screed and auger hydraulicsVOG-006Carry a spareAir filter, primary and safety elementEngine intake
