Hamm HC 100
Also available as HC 119i, HC 119iD, HC 139iD
- 10,450 kg
- Operating Weight
- 2,140 mm
- Drum Width
The Hamm HD 109i VV is a tandem vibratory roller featuring dual vibrating drums (front and rear), an articulated steering frame, and a compact yet powerful build engineered for precise asphalt compaction on medium-scale road construction projects.
Hamm HD 109i VV
Larger tandem roller at ten tonnes, for higher tonnage asphalt paving trains.
- 10,060 kg
- Operating Weight
- 1,680 mm
- Drum Width
Talk to a specialist
Add HD 109i VV and any other machines to one enquiry. We do not publish prices, our team will call you to discuss specification.
Hamm HD Series
3 builds, differing by class
HD 99i VV9.3 t, two vibrating drumsHD 109i VV10.1 t, two vibrating drumsHD 12B G VVCompactLine, 2.9 t
Operating Weight: 9,310 kg, 10,060 kg, 2,860 kg. Drum Width: 1,680 mm, 1,680 mm, 1,200 mm
Higher static load than the HD 99i
Keeps pace with high output paving trains
Same 1,680 mm drum width
Fewer passes to reach density
Larger tandem roller at ten tonnes, for higher tonnage asphalt paving trains.
The heavier sibling of the HD 99i VV, chosen when the paver is running at a rate the lighter roller cannot keep up with. Same drum width, more static load, so density is reached in fewer passes behind a high output paving train.
Key Features
- Higher static load than the HD 99i
- Keeps pace with high output paving trains
- Same 1,680 mm drum width
- Fewer passes to reach density
At a Glance
- Operating Weight
- 10,060 kg
- Drum Width
- 1,680 mm
About Hamm: Soil compactors and tandem rollers, with the HC and HD series built at the Wirtgen Group plant in Pune and homologised for the region.
View the full Hamm rangeFull technical data for the HD 109i VV. These figures also power the catalogue filters, so what you filter on is what is shown here.
Engine & Power
| Engine Manufacturer | John Deere |
|---|
Weight & Dimensions
| Operating Weight (kg) | 10,060 kg |
|---|
Compaction Performance
| Drum Width (mm) | 1,680 mm |
|---|---|
| Compaction System | Vibration |
Specifications are indicative and subject to confirmation against the current datasheet. Contact our team for available options and configurations.
How well this machine suits each type of work, rated by our team rather than derived from a generic rule.
Highway Construction
Best matchNew national highway alignments and multi-lane carriageways requiring high output paving and compaction.
94% fit
Airport & Runways
Strong matchRunway, taxiway and apron construction demanding tight surface tolerance and evenness.
88% fit
The service schedule for the Hamm HD Series, by hour meter reading. Every build in the family shares it. Our service team carries these out, and the parts each one needs are held in Kathmandu.
- 150 hGear oil and filter change
- 2100 hEngine oil and oil filter change
- 3500 hEngine oil and gear oil filter change
- 41,000 hEngine oil, gear oil and hydraulic oil filter change
Readings are the manufacturer's intervals. Dust, gradient and duty cycle all shorten them in practice, so treat these as the latest a service should happen rather than the earliest.
Book a serviceDocumentation for the HD 109i VV. The spec sheet is generated from the same data as this page, so it can never contradict it.
HD 109i VV Specification Sheet
Branded, print ready, always current. Opens in the browser and saves as PDF.
Ask us for any document you need and we will send it directly.
Keep it running
Recommended Spare Parts
The parts most often needed for the HD 109i VV, ordered by how quickly their wear stops the machine. Add any of them to the same enquiry as the machine.
HAM-T-012Carry a spareOscillation drive beltOscillation drum drive, HD-O modelsHAM-T-014Carry a spareChassis grease, lithium EP2Articulation joint, steering, drum bearingsHAM-T-002Carry a spareEngine oil, 15W-40 dieselDeutz engine, per service intervalHAM-T-005Carry a spareHydraulic oil, HVLP 46Propulsion and vibration hydraulicsHAM-T-006Carry a spareAir filter elementEngine intakeHAM-T-013Carry a spareCabin air filterOperator cab HVAC
